General:

By investing  considerable  amount  and  skilled  labour  we  have  developed  these  solid  state  power  supplies  with  a  unbeatable  performance  and  capacity. We  offer  a  wide  range  of  Solid  State  Power  Supply  at  very  competitive  prices.  The  latest  designs  and  technology  are  used.  These  Power  Supplies  extremely  high  level  of  reliability.

Features:

• Excellent  Stability
• Adjustable  Output
• Compact  In  Size
• Protected  Against  Over  Loading  And  Short  Circuiting

Specifications :

Input :230, Volt, ± 10%,  50  Hz.

Output :

• 0 – 30, Volt  at  2, Amp.
• 0 to ± 15 Volt  at  1, Amp.
• 0 - 5 Volt at  2, Amps.

Line Regulation : Better  than  ±  0.05%  for  ± 10%  changes  in  mains.

Load Regulation :    Better  than  ± 0.05%  for  no  load  to  full  load.

Ripples : Less  than  1, mVolt  at  full  load.

Protection :   The  unit  is  fully  protected  against  short  circuiting  and  over  loading.

Meter : To measure any of the output voltage or any external voltage.

Weight : 12Kg Approximately

Dimension : 400mm × 300mm × 140mm

Note : There may be any change in specification due to continuous R & D without notice.
